SCK13104MFY

NTC Thermistor
Product Detail
Design Leaded Type
Size (Diameter) (mm) 13
Thickness (mm) 2.5~6.0
Height Max. (mm) 17.5
Pitch (Nor.) (mm) 7.5±0.5
Lead Wire Diameter (Nor.) (mm) 0.8±0.02
Lead Shape Y kink lead
R25, Resistance at 25℃ (Ohm) 10
Tolerance of R25 (±%) ±20%
Max. Power Dissipation at 25℃ (W) 3.1
Thermal Time Constant (sec) 66
Max. Current at 25℃ (A) 4
R@Imax, Residual Resistance at 25℃ (Ohm) 0.217
Recommend Capacitance @120Vac (uF) 1880
Recommend Capacitance @240Vac (uF) 470
Operating Temperature (Tmin~Tmax) (℃) -40 ~ +200
Packaging Bulk
Automotive Grade Product No
Approval UL/CUL/TUV/CQC
Environmental RoHS & Halogen Free
